ASC2202C-S
Access Controller
> TCP/IP communication.
> Two communication protocols: RS-485 and Wiegand.
> Supports storing 100,000 user and 500,000 card-swiping records.
> Supports multi-door interlock, multi-user unlock, anti-passback, and remote unlock.
> Supports reader tamper alarm, intrusion alarm, unlocking timeout alarm, duress alarm, invalid card exceeding threshold alarm, and incorrect password alarm.
> Supports built-in RTC, manual time fixing, and automatic time fixing.
> Data can be saved permanently in case of power failure; supports online upgrade.
> Power supply through storage battery.
> Supports watchdog mechanism to ensure the operation stability.
System
Main Processor
Embedded processor
Internet Protocol
IPv4; TCP; UDP
OSDP Protocol
Yes
SDK
Yes
Basic
Product Appearance
Type C Iron Container
Buzzer
Yes
Casing Material
SECC steel board
Function
Unlock Mode
Card swiping; Remote; Password; Fingerprint
Period List
128
Holiday Period
128
Network Update
Yes
First-Card Unlock
Yes
Remote Verification
Yes
Blocklist/Allowlist
Yes
Peripheral Card Reader
2-Channel RS-485 card reader
2-Channel Wiegand card readerMulti-door Interlock
Yes
Group Combination
Card swiping; password; fingerprint
Real-Time Surveillance
Yes
Multiple Authentication
Yes
User
User (Card) Type
General user; VIP user; patrol user; guest user; blocklist user; other user
Capacity
User
100,000
Fingerprint
3,000
Card
100,000
Record Capacity
500,000
Port
RS-485 Port
3 × RS-485 ports
Wiegand
2 × Wiegand ports
Network
1 × 10/100 Mbps Ethernet port
Alarm Input
2 (digital quantity)
Alarm Output
2 (relay)
Alarm Linkage
Yes
Exit Button
2
Door Status Detection
2
Lock Control
2 channels, NO by default
Alarm
Anti-Passback
Yes
Tamper
Yes
Duress
Yes
Door Unlock Timeout
Yes
Intrusion
Yes
Illegal Card Exceeding Threshold
Yes
Duress Fingerprint
Yes
General
Power Supply
100-240 V AC
IP Rating
IP20; Ik04
Power Consumption
≤ 0.8 W (standby), ≤ 39.6 W (working)
Product Dimensions
337 mm × 272 mm × 90 mm (13.27”× 10.71”× 3.54") (H × W × D)
Packaging Dimensions
472 mm × 352 mm × 163 mm (18.58" × 13.86" × 6.42") (H × W × D) (one product in an inner carton)
Operating Temperature
–30°C to +60°C (–22 °F to +140 °F)
Operating Humidity
5%–95% RH (non-condensing)
Operating Environment
Indoor
Gross Weight
3.5 kg (7.72 lb)
Installation
Surface mount
Certification
CE; FCC; UL
