Capacity

Capacity

1500 VA

Input

Input Voltage

150–275 VAC

Input Current

4.3 A

Rated Input Frequency

50/60 Hz

Power Factor

0.85

Output

Output Voltage

220 VAC ± 10%

Output Current

Mains supply: 4 A

Battery powered: 3.6 A

Output Power

Mains supply: 900 W

Battery powered: 800 W

Output Frequency

50/60 Hz

Switch Time

<10 ms

Output Wave

Pure sine wave (main electricity mode) Modified sine wave (battery mode)

Battery

Built-in Battery

Yes

Battery Type

Lead-acid battery

Qty.of Battery

12 V, 9 Ah × 2

Charging Current

≤2 A

Limited Charge Voltage

13.75 V

Charging Time

Charges up to 90% in 6 hours

Indicators

Status Indicator Light

Battery powered: The red light flashes once every 6 seconds

Mains supply: Green light is solid on

Charging while shutdown: The yellow light flashes once every 20 seconds

Charging while on: The green light is solid on and the yellow light flashes once every 20 seconds.

Alarm

Alarm Indicator

Battery powered: Alarms one sound every 6 seconds

Low power: Alarms one sound every 1 second

Overload: Alarms one sound every 0.5 seconds

Protection

Protection

Overload, heavy discharge and overcharge

Plugs and Sockets

Input Plug

European standard

Input Cable Length

1 m (39.37 ft)

Socket Standard

European standard

Number of Output Sockets

4

Structure

Product Dimensions

360 mm × 122 mm × 195 mm (14.17" × 4.80" × 7.68")

Packaging Dimensions

473 mm × 236 mm × 310 mm (18.62" × 9.29" × 12.20")

Casing Material

Steel + plastic

Appearance Color

Black

Net Weight

11 kg (24.25 lb)

Gross Weight

11.7 kg (25.79 lb)

Environment

Operating Temperature

0 °C–40 °C (32 °F to 104 °F)

Operating Humidity

0–90% RH

Storage Temperature

0 °C–40 °C (32 °F to 104 °F)

Storage Humidity

0–90% RH

Certifications

Certifications

CE
