Camera

Image Sensor

Panoramic network camera: 1/1.8”CMOS PTZ camera: 1/1.8”CMOS

Max. resolution

Panoramic network camera: 4096×1800

PTZ camera: 1920× 1080

Scanning System

Progressive

Electronic Shutter Speed

Panoramic network camera: 1/3 s-1/100000 s, manual or auto adjust

PTZ Camera: 1/1 s-1/300000 s, manual or auto adjust

Min. Illumination

Panoramic network camera:

0.001Lux(colour);0.0001Lux(black);

PTZ camera:

0.001Lux(colour);0.0001Lux(black);0Lux(IR on)

S/N Ratio

Panoramic network camera:51db
PTZ camera:51.5db

IR Distance

Panoramic network camera: — PTZ camera: ≥ 220 m (721.78t) (IR on)

IR On/Off Control

Auto/Manual

IR LEDs Number

Panoramic network camera：— PTZ camera: 7

Lens

Lens Type

Panoramic network camera:Fixed-focal

PTZ camera:Motorized vari-focal

Mount Type

Panoramic network camera:M16

PTZ camera: Core interface

Focal Length

Panoramic network camera 2.8 mm

PTZ camera: 5.62mm~208mm, 37x optical zoom

Max. Aperture

Panoramic network camera: F1.6

PTZ camera: F1.4

Field of View

Panoramic network camera:Horizontal: 180° Vertical: 80°~85°

PTZ camera:Horizontal:

Horizontal: 2.61°~59.61°

Vertical: 1.48°~34.92°

Diagonal: 3°~66.96°

Iris Type

Panoramic network camera: Fixed aperture PTZ camera: Auto

Close Focus Distance

Panoramic network camera: 0.2m(0.66ft)

PTZ camera:0.1m~1m(0.33ft~3.28ft)

DORI Distance

Detect

Observe

Reconize

Identify

Panoramic network camera

29.0m

(95.14ft)

11.6m

(38.05ft)

5.8m

(19.02ft)

2.9m

(9.51ft)

PTZ camera

1930.7m

(6334.31ft)

772.27m

(2533.69ft)

386.1m

(1266.73)

193.1m

(633.53ft)

Smart Event

IVS

Intrusion, tripwire

Video

Video Compression

H.265; H.264; H.264H; H.264B; MJPEG

Smart Codec

Smart H.264+

Smart H.265+

Video Frame Rate

Panoramic network camera:Main stream(4096×1800@1~30fps),Sub Stream(1024×452@1~30fps),Third Stream(1920×832@`~30fps)

PTZ camera:

Main stream(1920×1080@1~30fps),Sub Stream(704×480@1~30fps),Third Stream(1280×720@1~30fps)

Stream Capability

3 Streams

Resolution

Panoramic network camera:

4096 × 1800; 4800 × 1920; 3840 × 1680; 3200 × 1280; 2880 × 1264; 2048 × 900; 1920 × 832; 1600 × 640; 1280 × 560; 1024 × 452

PTZ camera:

1920 × 1080; 1280 × 960; 1280 × 720; 704 × 576; 704 × 480; 352 × 288; 352 × 240

Bit Rate Control

Panoramic network camera: CBR/VBR

PTZ camera:CBR/VBR

Video Bit Rate

Panoramic network camera:

H.264:112kbps ~25599Kb/S

H.265:44kbps ~15494Kb/S

PTZ camera:

H.264:24kbps ~10752Kb/S

H.265:9kbps ~6400Kb/S

Day/Night

Auto (ICR)/Color/B/W

BLC

Yes

HLC

Yes

WDR

Panoramic network camera:DWDR

PTZ camera: WDR (120 dB )

White Balance

Panoramic network camera:Auto/Natural/street lamp/outdoor/manual/regional Custom

PTZ camera: Auto/indoor/outdoor/tracking/manual/sodium lamp/natural/street lamp

Gain Control

Auto/Manual

Noise Reduction

3D NR

Motion Detection

Disable/Enable

Region of Interest (RoI)

Yes (4 areas)

Electronic Image stabilization(EIS)

Panoramic network camera: — PTZ camera: Yes

Smart IR

Panoramic network camera: — PTZ camera: Yes (Adjusted by user.)

Defog

Panoramic network camera: — PTZ camera: Yes

Image Rotation

0°/180°(PTZ camera)

Privacy masking

4 areas(Panoramic network camera);24 areas(PTZ camera)

Audio

Audio Compression

G.711Mu;G.711A;G.726

Network

Network

RJ-45 (10/100/1000 Base-T)

Protocol

IPv4;IPv6;HTTP;HTTPS;TCP; UDP;ARP;RTP ;

RTSP;RTCP; RTMP;SMTP;FTP;SFTP;DHCP;DNS;DDNS; QoS;UPnP;NTP;Multicast;ICMP;IGMP;NFS;SAMBA;PPPoE;802.1x;SNMP

Interoperability

ONVIF (Profile S/Profile G); CGI; Milestone;Genetec

User/Host

20 (Total bandwidth: 1000 M)

Edge Storage

FTP;SFTP; Micro SD card (support max. 256 G); Dahua Cloud; NAS

Browser

Chrome 42

Firefox 52

IE7;IE8;IE9;IE11

Management Software

EVS5XX,EVS7XX,NVR5X-I,NVR4X-4KS2 ,M70,IVSS7X ,DSS Pro&DSS express

Certification

Certification

CE-LVD: EN60950-1
CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU
FCC: 47 CFR FCC Part 15, Subpart B
UL/CUL: UL60950-1 CAN/CSA C22.2 No.60950-1-07

PTZ Dome

Pan Range

Pan: 0° to 360° endless
Tilt: –12° to 90°, auto flip 180

Manual Control Speed

Pan: 240°/s
Tilt: 120°/s

Remote Lens Reset

Yes

Preset

300

Tour

8 Tour (up to 32 preset per tour)

Pattern

5 patterns

Scan

5

Power-off Memory

Yes

Idle Motion

Preset/Pattern/Tour/Scan

Time Task

Yes

Three-dimensional Positioning

Yes

PTZ Limit

Yes

Position Display

Yes

Information Display

Yes

Time Display

Yes

Port

Optical Fiber

FC,single mode, single fiber

Audio Input

2 channels (terminal)

Audio Output

2 channels (terminal)

Alarm Input

7 channels in: 5mA 3V–5V DC

Alarm Output

3 channels out: 1,000mA 30V DC/500mA 50V DC

Power

Power Supply

DC36V

Power Consumption

MAX:67.9W

Environment

Operating Temperature

-40°C to +70°C(-104°F to +158°F)

Operating Humidity

≤95%

Storage Temperature

-40°C to +70°C (-104°F to +158°F)/Less than 95% RH

Ingress Protection

IP66;IK10(optional)

Structure

Enclosure

Metal + Plastic

Dimensions

Φ383 mm × 389.8 mm (Φ1256.56 ft × 1279.8 ft)

Net Weight

14.3 kg (31.53 lb)

Gross Weight

19.5 kg (42.99 lb)
